Signage Solutions Multi-Touch Display

86BDL4152T/75

Signage Solutions Multi-Touch Display

86BDL4152T/75

Chasing innovation

Amaze your guests with a smarter, faster, signage display. With integrated WiFi, designed for running Android apps, and multiple touch points, it's the next evolution in signage solutions.

Signage Solutions Multi-Touch Display

Chasing innovation

Amaze your guests with a smarter, faster, signage display. With integrated WiFi, designed for running Android apps, and multiple touch points, it's the next evolution in signage solutions.

Chasing innovation

Amaze your guests with a smarter, faster, signage display. With integrated WiFi, designed for running Android apps, and multiple touch points, it's the next evolution in signage solutions.

Signage Solutions Multi-Touch Display

Chasing innovation

Amaze your guests with a smarter, faster, signage display. With integrated WiFi, designed for running Android apps, and multiple touch points, it's the next evolution in signage solutions.

Chasing innovation

powered by Android

  • 86"
  • Powered by Android
  • 500cd/m²
Save and play content with internal memory

Save and play content with internal memory

Save and play content with internal memory. Upload your media into the display and playback content immediately. Working in conjunction with the internal browser, it also serves as a memory cache when streaming online content. If the network ever fails, the internal memory keeps content running by playing a cached version of the content, ensuring that your media stays up even if the network goes down.

Keep your content up and running with FailOver

Keep your content up and running with FailOver

Keeping your content up and running is critical for demanding commercial applications. While it is unlikely you will face a content disaster, FailOver provides content protection with a revolutionary technology that plays back-up content on screen in the event of a media player failure. FailOver automatically kicks in when the primary input fails. Simply select a primary input connection and a FailOver connection and your ready for instant protection.

SmartPower for energy saving

SmartPower for energy saving

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

CMND: Take control of your displays

CMND: Take control of your displays

A robust display management platform, CMND puts the power back into your hands. Update and manage content with CMND & Create or control your settings with CMND & Control. It's all possible with CMND.

Manage settings of multiple displays with CMND & Control

Manage settings of multiple displays with CMND & Control

With CMND & Control, easily manage multiple displays in a central location. With real time display monitoring, setting and software updates from a remote location, and the ability to customize and configure multiple displays at once, such as video wall or menu board displays, controlling your suite of displays has never been easier.

Create and update content with CMND & Create

Create and update content with CMND & Create

Design and create compelling content with CMND & Create, a powerful authoring tool. With a drag and drop interface, preloaded templates, and integrated widgets, you'll be able to amaze your customers with compelling content. Available in portrait and landscape mode.

Connect and control your content via the cloud

Connect and control your content via the cloud

Connect and control your content via the cloud with the integrated HTML5 browser. Using the Chromium based browser, design your content online and connect a single display, or your complete network. Show content in both landscape and portrait mode, with fullHD resolution. Streaming content can also be shown in a PIP (picture-in-picture) window. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlists

Android: Run your own app or choose your favorite app to run

WIth Android OS integrated into the display, you can work with the most developed OS on the planet and save your own app directly into the display. Or, choose from the large library of Android apps and play content from there. With the built-in scheduler, you can daypart your apps and content based on your customer and time of day and with the auto orientation feature, showing content in portrait or landscape is as simple as turning the display.

Enhance your connectivity with an integrated mPCIe slot.

With an integrated PCI slot, you can connect a WiFI/bluetooth or 4G LTE module, allowing for even greater communication with the display. Machine to machine communication is also enhanced, with numerous configurations available for customers to use, such as the ability to expand product features or signal-handling capability.

Ensure your content is running with automatic screenshots

Content is king, and with the automatic screenshot feauture, you can make sure that your content is up and running at all times. Screenshots are taken throughout the day, which are then stored in the FTP server. From there, the screenshots can be viewed no matter when, or where you are.

Simplify meetings with FailOver for conferencing

Using FailOver, simplify your presentations and videoconferencing. When a meeting or conference room is not in use, background content can run from whatever input source you choose. When the meeting starts and you need to share a presentation or your screen, simply connect your computer and the display automatically switches inputs and shows what's on your screen, with no need to manually switch inputs.

Android: Run your own app or choose your favorite app to run

With Android integrated into the touch display, you can work with the most dveloped OS on the planet, and save your own app directly into the display. This also means, for the built-in apps, like the browser, it's touch capable right out of the box. Just connect the power and you've got immediate interactivity. You can also use the built-in scheduler to daypart your apps and content based on the time of day. And, using the auto orientation feature, switching from portrait to landscape content is as simple as turning the display.

Technical Specifications

  • Connectivity

    Audio output
    • 3.5mm jack
    • SPDIF
    Video input
    • DisplayPort
    • DVI-D (x1)
    • VGA (Analog D-Sub)
    Audio input
    3.5 mm jack
    Other connections
    • mPCIe
    • micro SD
    • micro USB
    • USB power outlet (5 V. 2 amp)
    • OPS
    Video output
    DisplayPort
    External control
    • RJ45
    • RS232C (in/out) 2.5 mm jack
    • IR (in/out) 3.5 mm jack
  • Picture/Display

    Diagonal screen size (metric)
    217.42  cm
    Diagonal screen size (inch)
    85.6  inch
    Aspect ratio
    16:9
    Panel resolution
    3840 x 2160
    Pixel pitch
    0.4935 (H) x 0.4935 (V)
    Optimum resolution
    3840x 2160 @ 60Hz
    Brightness
    500  cd/m²
    Display colors
    1.07 billion
    Contrast ratio (typical)
    1200
    Dynamic contrast ratio
    500,000:1
    Response time (typical)
    12  ms
    Viewing angle (horizontal)
    178  degree
    Viewing angle (vertical)
    178  degree
    Picture enhancement
    • 3/2 - 2/2 motion pull down
    • 3D Combfilter
    • Motion compens. deinterlacing
    • 3D MA deinterlacing
    • Dynamic contrast enhancement
    • Progressive scan
  • Convenience

    Placement
    • Landscape
    • Portrait
    Picture in picture
    PIP
    Tiled Matrix
    Up to 15 x 15
    Screen saving functions
    Pixel Shift, Low Bright
    Keyboard control
    • Hidden
    • Lockable
    Signal loop through
    • RS232
    • IR Loopthrough
    Ease of installation
    Smart Insert
    Energy saving functions
    Smart Power
    Network controllable
    • RJ45
    • RS232
    • One Wire (HDMI-CEC)
    • HDMI (One Wire)
  • Sound

    Built-in speakers
    2 x 10W RMS
  • Power

    Mains power
    100 ~ 240 VAC, 50 ~ 60 Hz
    Consumption (Typical)
    262  W
    Consumption (Max)
    450 W
    Standby power consumption
    <0.5 W
  • Supported Display Resolution

    Computer formats
    • 1024 x 768, 60, 75Hz
    • 1024x768, 60,70Hz
    • 1152 x 864, 60, 70, 75Hz
    • 1152 x 900, 66Hz
    • 1280 x 720, 60,70Hz
    • 1280 x 768, 60Hz, 75Hz
    • 1280 x 800, 60,75Hz
    • 1280 x 960, 60Hz
    • 1280x1024, 60,67,75Hz
    • 1360 x 768, 60Hz
    • 1366 x 768, 60Hz
    • 1400 x 1050 ,60, 75Hz
    • 1440 x 1050, 60Hz
    • 1440 x 900, 60, 75Hz
    • 1600 x 1200, 60Hz
    • 1600 x 900, 60Hz
    • 1680 x 1050, 60Hz
    • 1920 x 1080, 60Hz
    • 1920 x 1200, 60Hz
    • 640 x 350, 70Hz
    • 640 x 480, 60, 67, 72, 75Hz
    • 720 x 400, 70Hz
    • 800 x 600, 56, 60, 72, 75Hz
    • 832 x 624, 75Hz
    • 848 x 480, 60Hz
    • 960 x 720, 60,75Hz
    • 960x720, 75Hz
    Video formats
    • 480p, 60Hz
    • 480i, 60Hz
    • 1080i, 50Hz
    • 1080i, 60Hz
    • 1080p, 50, 60Hz
    • 4K x 2K
    • 576i, 50Hz
    • 576p, 50Hz
    • 720p, 60Hz
    UHD Formats
    • 3840 x 2160, 24, 25, 30, 60 Hz
    • 4096 x 2160, 24 Hz
  • Dimensions

    Smart Insert mount
    100 x 100 mm, 100 x 200 mm
    Set Width
    1957  mm
    Product weight
    96.21  kg
    Set Height
    1128  mm
    Set Depth
    104.9  mm
    Set Width (inch)
    77.05  inch
    Set Height (inch)
    44.4  inch
    Wall Mount
    600(H)x400(V) mm, M8
    Set Depth (inch)
    4.13  inch
    Bezel width
    28.4 mm(Even bezel)
    Product weight (lb)
    212.1  lb
  • Operating conditions

    Altitude
    0 ~ 3000 m
    Temperature range (operation)
    0 ~ 40  °C
    MTBF
    50,000  hour(s)
    Relative humidity
    20 ~ 80  %
    Temperature range (storage)
    -20 ~ 60  °C
  • Multimedia Applications

    USB Playback Video
    • MKV
    • MP4
    • MPEG
    • MPG
    • TS
    • VOB
    • WMV
    • ASF
    • AVI
    • FLV
    • WEBM
    USB Playback Picture
    • BMP
    • JPEG
    • JPG
    • PDF
    USB Playback Audio
    • AAC
    • M4A
    • MP3
    • WMA
  • Internal Player

    CPU
    • Dual-Core Cortex-A72 @2GHz
    • Quad-Core Cortex-A53 @ 1.5GHz
    GPU
    ARM Mali-T860 MP4
    Memory
    4GB RAM
    Storage
    64G eMMc
  • Multi-touch Interactivity

    Touch points
    10 simultaneous touch points
  • Accessories

    Included accessories
    • Quick start guide
    • RS232 cable
    • AC Power Cord
    • IR sensor cable (1.8M)
    • Remote Control & AAA Batteries
    Included Accessories
    • IR sensor cable (1.8 m) (x1)
    • M2 screw (x3)
    • M3 screw (x1)
    • Philips logo (x1)
    • RS232 Daisy chain cable (x1)
    • SD card cover (x1)
    • Wifi dipole antenna (x2)
    Optional accessories
    ColourCalibrationKit (CCK4602)
    Stand
    BMO5922 (Optional)
  • Miscellaneous

    On-Screen Display Languages
    • English
    • French
    • German
    • Spanish
    • Polish
    • Turkish
    • Russian
    • Italian
    • Simplified Chinese
    • Traditional Chinese
    • Arabic
    • Japanese
    • Danish
    • Dutch
    • Finnish
    • Norwegian
    • Portuguese
    • Swedish
    Warranty
    3 year warranty
    Regulatory approvals
    • EnergyStar 7.0
    • CE
    • FCC, Class B
    • UL/cUL
    • CCC
    • C-Tick
    • RoHS
    • GOST
    • BSMI
    • CB
    • J-Moss
    • PSE
    • VCCI

What's in the box?

Other items in the box

  • Quick start guide
  • RS232 cable
  • AC Power Cord
  • IR sensor cable (1.8M)
  • Remote Control & AAA Batteries
  • Optional accessories: ColourCalibrationKit (CCK4602)
