Zenition 30
Mobile C-arm with Flat Detector
Zenition 30
Mobile C-arm with Flat Detector
Give your surgical teams simple, more flexible imaging to make fast, informed decisions with the Philips Image Guided Therapy Mobile C-arm System 3000 – Zenition 30. Flat Detector technology along with advanced imaging algorithms and a Personalized IQ feature provide outstanding image quality and dose efficiency, Unique Surgeon Control and the Touch Screen Module empower end users by giving more control, while the Electromagnetic brakes reduce manual effort.
Clinical image gallery
Features
Dedicated pediatric mode
Exam settings enable low dose modes for pediatrics. Imaging and dose settings can be tailored to small objects and pediatric patients by removing the X-ray grid. 84% of users believe the pediatric mode could lead to more confidence in treating pediatric patients.²
Achieve your economic goals with a reliable system
Zenition 30 comes with a promise of higher uptime over its entire lifecycle thanks to a highly reliable design. Philips Remote Expert Connect enables proactive service, remote diagnosis and resolution further boosting the availability of the system for your busy OR. With our Healthcare Operational Services multi-tier service agreements portfolio, you will be able to address your maintenance challenges and balance your financial goals.
Reduce manual effort and optimize workflow
Reduce manual effort to lock and unlock brakes with the controls for the Electromagnetic brakes provided on either side of the C-stand. This further contributes to an improved workflow for the technician, as all the brakes can be released from one place. 98% of users believe that the electromagnetic brakes support an efficient workflow.³
Specifications
- X-ray generation
- X-ray generator
- Monoblock 40 kHz high frequency generator
- X-ray tube
- Fixed Anode (tube)
- Maximum generator output
- 2.1 kW or 4 kW
- Flat detector
- Flat detector
- Trixell amorphous silicon detector
- Matrix size
- FD11: 1024 x 1024 pixels
- Detector Area
- FD11: 20 cm x 20 cm (7.9" x 7.9")
- Pixel pitch
- 200 μm
- Connectivity
- Digital video out (optional)
- 2 DVI connectors left and right monitor
- USB storage
- PNG, MP4, BMP
- Wireless data transfer
- Standard
- Video in (optional)
- S-Video, DVI (digital and analog), SDI
- Advanced DICOM/IHE package⁵
- Modality Worklist Mgmt, Modality Performed Procedure Step, Storage Commit
- Options
- Image Viewer
- Multi-Modality Viewer
- Tank laser aiming device
- Laser aimer projects a X-hair from the X-ray tank towards the Flat Detector
- Flat detector laser aiming device
- Laser aimer projects a crosshair from the detector towards the X-ray tank
- Surgeon control⁵
- Electromagnetic brake buttons on the detector
- Geometry
- C-arc depth
- 73 cm / 29"
- C-arc
- Color coded, fully counterbalanced C-arc
- Source Image Distance
- 100 cm / 39.4"
- Angulation
- 156° rotation (+90° / -66°)
- Lowest lateral position
- 106 cm / 41.7"
- Free space in C-arm
- 765 mm / 30.1"
Related products
- Experience exceptional imaging clarity and flexibility for performing a wide variety of cases with our fourth generation Flat Detector systems. Part of the Zenition mobile C-arm family – a series of harmonized mobile C-arm that offers proven ease of use and future-fit capabilities.
- Point-and-shoot simplicity and reliable uptime make the Zenition 50 mobile C-arm with image intensifier the ideal systems for intensive use in interventions and surgeries. Part of the Zenition mobile C-arm family – a series of harmonized mobile C-arms that offers proven ease of use and future-fit capabilties.
- Power the future of routine surgeries with Philips Image Guided Therapy Mobile C-arm System 1000 – Zenition 10. This Flat Detector (FD) system offers high quality imaging, high uptime and an efficient workflow in a powerfully compact design for your daily mix of orthopedic, trauma and other procedures.
Disclaimer
Zenition mobile C-arm systems are available for sale in a limited number of countries. Please check with your local representative for availability in your market.
Actual product representation may vary.
1. Results obtained during claims substantiation study performed in February and September 2022 by Use-Lab GmbH, an independent company. Response is based on 42 respondents (26 surgeons & radiologists and 16 technologists & nurses) from the EU and US, who answered a questionnaire subsequent to a usability study with additional hands-on time with the system.
2. Results obtained during claims substantiation study performed in February and September 2022 by Use-Lab GmbH, an independent company. Response is based on 37 respondents (26 surgeons & radiologists and 11 technologists & nurses) from the EU and US, who answered a questionnaire subsequent to a usability study with additional hands-on time with the system.
3. Results obtained during claims substantiation study performed in February and September 2022 by Use-Lab GmbH, an independent company. Response is based on 50 respondents (26 surgeons & radiologists and 24 technologists & nurses) from the EU and US, who answered a questionnaire subsequent to a usability study with additional hands-on time with the system.
4. The X-ray dose reductions refer to specific features and will vary depending on the dose parameters selected.
5. Optional for 2.1 kW configuration and standard for 4 kW configuration.
