C6-2 Transducer
Broadband curved array transducer
Ultrasound
  • InnoSight in scanning room with doctor scanning OB patient with C6-2
  • Doctor scanning abdomen of patient
  • InnoSight in scanning room with spouse and doctor scanning OB patient with C6-2
  • InnoSight patient bedside abdominal scan with doctor and patient, using C6-2 transducer
  • Affiniti 30 with OB patient being scanned with C6-2
  • InnoSight emergency department, abdominal scan with doctor and patient
  • C6-2 broadband curved array transducer

C6-2 Transducer

Broadband curved array transducer
Ultrasound
The C6-2 curved array transducer has 6 to 2 MHz extended operating frequency range and offers high performance for OB/GYN, Fetal Echo, Abdominal and Interventional applications.

Clinical image gallery

  • Liver and Hepatic Veins in 2D using C6-2 transducer
    Liver and Hepatic Veins in 2D using C6-2 transducer
  • Fetal ultrasound image shown using C6-2 transducer
    Fetal ultrasound image shown using C6-2 transducer
  • Fetal ultrasound profile image shown using C6-2 transducer
    Fetal ultrasound profile image shown using C6-2 transducer
  • OB ultrasound image shown with CPA using C6-2 transducer
    OB ultrasound image shown with CPA using C6-2 transducer
  • Spleen in 2D using C6-2 transducer
    Spleen in 2D using C6-2 transducer
Specifications
  • Specifications
    Technology
    Broadband
    Number of elements
    128
    Frequency range
    6 - 2
    Array Type
    Curved
    Aperture
    63.7
    Field of view
    72°
    Applications
    General purpose abdominal (adult and pediatric, including vascular), obstetrical, gynecological, urology, and interventional applications
    Biopsy capable
    Yes
    Image Fusion Navigation capable
    No
