Multiva 1.5T
Magnetic Resonance Imaging system
Multiva 1.5T
Magnetic Resonance Imaging system
Get fast, right first time imaging for a wide range of routine and advanced applications with Philips Multiva 1.5T magnetic resonance imaging (MRI) system. Clinicians need less time to make a confident, accurate diagnosis, improving throughput and referral status.
Features
Cost control made easy
Compact siting, power-saving features , service, and education that help users increase system utilization help you keep costs under control.
IntelliSpace Portal
IntelliSpace Portal delivers easy clinical workflow and collaboration tools to help you streamline your daily routine. Unlock the power of CT, MR, molecular imaging, and ultrasound systems with rich clinical applications accessible wherever you are.
Fast, robust imaging for diverse exams
oStream analog-to-digital signal conversion inside the scan room, at the magnet, increases signal clarity to deliver fast, robust imaging.
Specifications
- Magnet
- Magnet weight
- 2900
- Bore design
- 60
- Maximum FOV
- 53
- Ultra compact, Zero Boil off magnet
- Yes
- RF receive
- Number of channels
- 16
- Channel bandwidth
- 3 MHz per channel
- Sampling
- Direct Digital Sampling (DDS)
- Preamplifiers
- All RF coils include built in dedicated low noise preamplifiers for optimal signal-to-noise
- Galaxy gradients: Performance
- Max Amplitude**
- 33
- Effective
- 57
- 208 mT/m/ms
- Max slew rate**
- 120 mT/m/ms
- RF transmit
- Output power
- 18
- Amplitude resolution
- 16 bits
- Tuning
- Per patient rapid automatic power and frequency optimization
- Resolution parameters
- Max scan matrix
- 1024 (2048 optional)
- Max. number of slices
- 1024
- Patient environment: Patient aperture
- Length
- 60
- Bore design
- 60
- Patient aperture flare
- 119 cm (horizontally)
- Wireless patient physiological synchronization
- Yes
- Various acoustic noise reduction solutions
- Yes
- Patient transport system (optional)
- Dockable patient trolley (optional)
- Weight capacity
- 250 kg (550 pounds)
- Patient support working height
- 89 cm (35 inches)
- Patient support minimum height
- 52 cm (20.5 inches)
- SmartAssist Efficiency Assistance
- SmartSelect****
- Yes
- SmartExam (optional)
- Yes
- SmartLine (package dependent)
- Yes
- SmartLink (package dependent)
- Yes
- FlexStream workflow
- Total Spine studies***
- Zero coil handling
- Brain, NV, Body, MSK studies
- One ultra-light anterior coil
- Whole body exams***
- Zero coil handling
- Site planning: Power consumption
- Standby
- 4.6
- Ready
- 7.4
- Scanning*****
- 21.5
- Peak
- 27
- Minimum floor space
- 19.5 m2 (210 sq.ft.)
Related products
- Put quality first with Philips Ingenia 1.5T MRI system. Digital clarity and speed¹ help clinicians diagnose with confidence, explore new applications, and work productively. Great patient reviews build your image in the community. All supported by our commitment to helping you grow.
Disclaimer
*Hinged upon the unique FlexCoverage Posterior coil that provides neck-to-toe coverage without the need for any manual removal or repositioning, FlexStream enables imaging with fewer coils and reduces coil postioning and patient set-up time.
*Multiva 1.5T is not sold in USA
**On each axis. Amplitude deviation over full 53 cm FOV is <lt/>8%
***Using the optional HST and/or Flex MSK coils
****Available per Q4 2013
