Ingenia Prodiva 1.5T CS
A revolutionary workflow delivers speed – and productivity
Ingenia Prodiva 1.5T CS
A revolutionary workflow delivers speed – and productivity
Dependability and predictability are key to realizing your possibilities in an MR business. Philips Ingenia Prodiva 1.5T CS is designed to support your ambitions. Build your reputation for dependable MR services on our proven dStream digital broadband technology, used in over 2000 installations worldwide. The simplified Breeze workflow aids users with different levels of experience in easily performing consistent routine MR exams from day one. Low installation and siting expenses, continuous uptime support and easy upgrades provide predictable total cost of ownership and peace of mind.
Clinical image gallery
- 3D FFE WATS
- T2, T1 and T2 FatSat
- TRA TIR
- T2 SAG
- COR T1
- Non-contrast MRA
- MRCP
Features
Accelerate workflow by reducing the number of positioning steps
The Breeze Workflow reduces the number of positioning steps by up to 34%¹ and enables you to accelerate your daily exam workflow. Patient set-up is intuitive and takes minimal coil handling thanks to the Breeze Workflow.
Reduce energy costs
PowerSave technology combines efficient design with smart power management to help keep energy bills consistently low.
Reduce the need for costly remodelling
To allow your new MR to be sited in an existing room, Ingenia Prodiva 1.5T CS features a small fringe field on a lightweight magnet. This can reduce the need to make costly renovations, such as removing walls, raising ceilings or reinforcing floors.
Specifications
- Magnet system
- Field strength
- 1.5T
- Bore design
- 60 cm
- Magnet weight
- 2700 kg
- Typical homogeneity V-RMS
- ≤ 0.9 ppm (at 40 cm DSV)
- HeliumSave technology
- Yes (zero boil-off)
- Maximum FOV
- 50
- Cryogen boil-off rate
- 0 liter/hour (under normal operation)
- Stellar HP gradients
- Max. amplitude for each axis
- 33 mT/m
- Max. slew rate for each axis
- 120 T/m/s
- RF transmit
- Output power
- 18 kW
- RF Receive
- Number of independent receive channels
- Channel independent
- Location of analog-to-digital converter (ADC)
- Integrated coils: Inside the coil / Anterior coils: In dStream interface
- Signal chain from coil to reconstructor
- Fully digital
- dStream
- Yes
- Siting information
- Minimum siting requirement
- 3.35 m x 5.25 m
- Ceiling height (minimum)
- 2.35 m
- Single operator workflow
- SmartSelect
- Yes
- SmartExam
- Yes
- SmartStart
- Yes
- SmartLink
- Yes
- SmartLine
- Yes
Related products
- Support your clinical decisions by leveraging our imaging solutions built on proven dStream digital broadband technology, present in over 2000 installations worldwide. Accelerate patient throughput with a simplified Breeze Workflow. An intuitive user interface enhanced by highly guided and standardized examination procedures helps you perform routine MRI exams from day one. And with low installation and siting expenses, continuous uptime support and easy upgrades, you can continue to enhance your possibilities.
Disclaimer
1. Based on internal study comparing workflow with Achieva.<br>
2. Based on an internal study comparing workflow in a mix of brain, spine, MSK and body applications with the Achieva MR system.<br>
3. Normal operation is defined as typical scanning performed with uninterrupted availability of electricity, magnet cooling and excluding service actions.
4. Dependent on contract entitlement and local availability.
5. Compared to Philips scans without Compressed SENSE.
